Compact Power Meter

Comprehensive real-time monitoring, recording and analysis of single and 3-phase systems

제조사
KYORITSU
제품명
Compact Power Meter
제품번호
KEW6305
Comprehensive real-time monitoring, recording and analysis of single and 3-phase systems
Voltage, Current, Power Factor and Frequency measurements
Power analysis (Active, Apparent and Reactive power)
Energy analysis (Active, Apparent and Reactive power)
Active power accuracy: ±0.3%rdg±0.2%f.s.
Automatic wiring check function to prevent incorrect connections
Large memory capability (2GB) using built-in SD card interface
Real time & remote measurements using Android application
synchronous measurements between two units of KEW 6305
Wide selection of clamp sensors allow measurements from 0.1A to 3000A
The instrument automatically recognizes what kind of clamp sensor is connected to it

Windows software for data analysis and setting via USB port or Bluetooth
Free Android software "KEW smart 6305" is available
on "Google Play Store" (*)
  • Supporting Android ver. 2.2 - 4.4
  • WVGA (800 × 480) resolution or higher
(*)Please search "KEW Smart" in Google Play Store.
Communication charge may be incurred separately to download application.
TRUE RMSUSBBluetooth ®
