Clamp on Leak Hitester (CM4002/CM4003 출력, 외부전원기능 탑재 대체품)
1mA to 200A AC Leakage Current Clamp Meter with 10 µA Resolution to Analyze Distorted Waveforms
- Measure leak current using highly sensitive 10μA resolution (at 10.00
- Indicate 50/60 Hz leak current components with the filtering function
- 3283-20: EN 61010-2-032:2012 Type A to measure un-insulated hazardous
- 제조사
- HIOKI
- 제품명
- Clamp on Leak Hitester (CM4002/CM4003 출력, 외부전원기능 탑재 대체품)
- 제품번호
- 3283(단종모델)
• Measure leak current using highly sensitive 10μA resolution (at 10.00 mA range)
• Indicate 50/60 Hz leak current components with the filtering function
• Monitor leak current conditions in combination with a Memory HiCorder (monitor output, Model 3283 only)
• 3283-20: EN 61010-2-032:2012 Type A to measure un-insulated hazardous live conductors such as bus-bars
-
series_Clamps_E6-5XE.pdf
- 확장자 :
- 파일크기 :
- 2.99MB
